PMMA Lens Photoelectric Sensors for Storage Humidity 35-95%RH Performance and Efficiency

Name: PMMA Lens Photoelectric Sensors for Storage Humidity 3595RH Performance and Efficiency
Brand: KRONZ
Price: 1 USD

Cheap PMMA Lens Photoelectric Sensors for Storage Humidity 35-95%RH Performance and Efficiency wholesale

Brand Name : KRONZ

Model Number : KD50-120N

Place of Origin : Guangdong, China

Certification : CE

MOQ : 1

Price : Negotiable

Packaging Details : Polybag packing

Delivery Time : 5-8 working days

Payment Terms : T/T,Western Union,MoneyGram

Supply Ability : 10000 pieces per month

Linearity Accuracy : ±0.1%F.S.

Connection Type : Cable

Spot Size (max.) Far Range : 0.5x0.8mm

Factory Setting : 500μs（250mm：750μs）

Light Source : Red Laser Diode

Operating Temperature : -10~45°C

Shock Resistance : 50G（500m/s²）

Spot Size (max.) Near Range : 1.2x1.8mm

Contact Now

Product Description:

The photoelectric sensor product is a versatile and reliable short-range optical sensor designed for a variety of industrial applications. The sensor's housing features a rugged construction made of PBT material, which ensures durability and long-term performance. In addition, the lens is made of PMMA, which provides optical clarity and sensing accuracy.

How CMOS laser displacement photoelectric sensors work?

Laser Emission: The sensor emits a laser beam onto the surface of the target object.
Reflection: The reflected light is captured by the CMOS sensor at a certain angle (triangulation principle).
Displacement Calculation: The position of the reflected light spot on the CMOS sensor changes depending on the target’s distance. Based on this, the sensor calculates the displacement (distance to the object) with high accuracy.

PMMA Lens Photoelectric Sensors for Storage Humidity 35-95%RH Performance and Efficiency

Cable type	2 channels	KD50-120N series
Output signal		Switching Output: NPN (-N)
Detection range		120±60 mm
Full Scale (F.S.)		120 mm
light source		Red laser diode
Sampling period		Class 2 (Class II)
Sampling period		500 (250 mm: 750)
repeatability	High-speed mode	45 microns
	Other modes	30 microns
Storage temperature/humidity		-20~60°C/35~95%RH (no condensation, freezing)
Impact resistance		50G (500 m/s²)
Spot size (max)	Close up	1.2x1.8 mm
Housing material		Housing: PBT Lens: PMMA
Vibration resistance		10~55Hz, double amplitude 1.5mm, X, Y, Z direction, 2 hours each

应用:

KRONZ 光电传感器是多功能设备,由于其可靠的性能和先进的功能,可用于广泛的应用和场景.这些传感器是工业自动化,制造过程,机器人技术等的理想选择.

PMMA Lens Photoelectric Sensors for Storage Humidity 35-95%RH Performance and Efficiency
